Materiaalikaula trukkille

hakemus

---

Material Shovel can be used for steel and aluminum smelting company can achieve long-range, high-temperature environment of security operations.

ominaisuudet

---

Hydraulic system: hydraulic motor with a well-known foreign company's products; Rotary Manifold Seals are imported in the company's products.
Structural parts: the slewing bearing slewing bearings with large modulus, the load capacity; worm and worm involute tooth profile, can improve efficiency, reduce heat loss, but also to achieve self-locking feature.
Mechanical performance: the rotation of hydraulic oil on the road with two-way self-locking, ensuring safety at work.

Huomautus

---

①Obtain the actual capacity of the forklift and attachments from the forklift manufacturer,
②One/Two sets additional oil circuit required on forklift
③Please contact the sales from HUAMAI

Hydraulinen virtaus ja paine

---

Malli	Min.Hydraulinen virtaus (L / min)	Rec. Hydraulinen virtaus (L / min)	Suurin hydrauliikkavirta (L / min)	Min. Hydraulinen paine (bar)	Max. Hydraulinen paine (bar)
LMS**G	20	40	60	35	160

 Rotator-erittely

---

Malli	Rotaattorin nopeus	Rotatorin vääntömomentti
LMS**G	4.1r/min@57L/min	9000N.M@160Bar

vaihtoehdot

---

Mukautetut avausalueet
Asetettu lyhyt varsi tai kiinteä lyhyt varsi
Halkaistu pitkä käsivarsi
Erityiset tyynyt, kumityyny, polyuretaani-tyyny

sovellus:

Handling loose and free-flowing material like dry sand, stones, salt, fertilizer, dry chemicals, grain, etc.

Features and benefits:

Shovel is constructed from 6 mm steel plate.
Loading edge is sharp, straight line or toothed.
Dumping cylinders are enclosed for protection.
Mounting / removal is easy, with just 3 bolts.
Shovel has a 300 forward tilt to ensure full discharge of load.
Full control on shovel movement ensures dumping at desired rate.
